KBN1 Series Front Loading Turn Table Parts Washers

WORKING PRINCIPLES :

Washing is done in a completely isolated cabinet without manual operation. During this wash, 2-5 percent concentration alkali chemistry water penetrates all parts of the dirty part by specifically placed nozzles and water pumped from the tank via an electro stainless steel body pump. And the basket is rotating around itself to improve the washing effect from up, down, and sides. In this type of machine rinsing and drying is handled in the same cabinet. According to the demanded process, all parameters can be controlled via PLC control. According to all these identified parameters, washing can be done without any manual operation. This model is especially preferred for washing over height parts and in order to increase the washing quality of parts.

UTILIZATION FIELDS :

These devices are used for parts,
- Cleaning oil/Burr and contaminants on the surfaces,
- Preparing surface before painting,
- Removing the stain on Metal Surface,
- Cleaning the surfaces before welding.
Some of the industries where KBN1 Series parts washing machines are used are as follows;
- Automotive spare Parts Production Factories,
- Machine and part manufacturers,
- Medical Parts and Device manufacturers,
- Weapon and Ammunition Manufacturers,
- Work machines Repair and Maintenance Services,
- Bus Maintenance Services
- Truck and Heavy Vehicle Services,
- Motor Revision and Rectification Services
- Industrial Factory Maintenance Units
- Military Maintenance Units,

Features Distinguishes Dolfin from its Competitors,

Our After-Sales Service,
Full Compliance to CE Standards,
AISI 304 L/ 1.4301 Stainless Steel Main Body,
AISI 304 L/ 1.4301 Stainless Steel Pump,
AISI 304 L/ 1.4301 Stainless Steel Tank,
Washer Basket Structure,
Secure Full Protection,
Wide-Range Functionality

Standard Features :

- Certification in Compliance With CE Standards
- Trolley
- AISI 304 L/ 1.4301 Stainless Steel Main Body
- AISI 304 L/ 1.4301 Stainless Steel Tank
- AISI 304 L/ 1.4301 Stainless Steel Pump
- Board w/Failure Alarm
- Strengthened Washer Basket
- Side Driven Washer Basket
- Stainless Steel Removable Nozzle
- Dual Filtration System
- Stainless Steel in Pump Suction
- Resistance with Steel Heater
- Water Level Protection
- Heat Protection
- Timer
- Full Protection Against Electric Shock
- Emergency Stop Button Small Parts Basket
- Operating Temperature up to 90 Degrees
- Highly Resistant Special Gasket on Pump
- Cover with Pneumatic Piston
- Infrared Hand Protection
- Digital Indicator
- Steam Relief Fan
- Design with Easy-Maintenance

Optional Features :

- Oil Scraper (Disc Type)
- Automatic Tank Discharge Unit
- Precise Filtration
- Drier
- Acidic Washing Application
- Automatic Tank Filling

Do you want to get more details about our products ?

You can contact our professional team for detailed information.

Dolfin Parts Washing Machines are manufactured for more than 40 years. It has delivered more than 5,000 standard or specially designed parts washing machines to its customers in more than 30 countries on 5 continents.
